Tech Specs
Body
Finish
Powder coated.
Diffuser
Opal acrylic.
Mechanical
Luminaires mount directly over J box (by others).
Remote Emergency system
Emergency option provides a 1.5 hour (3hours for EU) emergency lighting facility. The remote system includes the inverter module, NiCad batteries and a remote wall/ceiling LED charge indicator and test switch. Maximum distance between wall/ceiling plate and luminaire is 15' (4.5m). Test switch fits a single gang box (not supplied).
Sensors
Compatible with Avi-On, Casambi, Enlighted, Lutron Vive, nLight, NX Lighting Controls, Osram, Philips, and others. Consult factory.
PoE
Can be integrated into your data network via Power over Ethernet (PoE) connectivity.
Drivers
HPF electronic drivers for 120-277V, 347 (EU-240V). The driver is integral to the fixture housing.
Reported L70 @25°C (77°F)
> 55,000 hrs @ 2000 lumens/ft (6000 lumens/m)
Estimated L70 @25°C (77°F)
> 165,000 hrs @ 2000 lumens/ft (6000 lumens/m)
Delivered lumens
Delivered lumens & LPW based on 4000K CRI 90+
Approvals
Damp Rated.
Designed by
Serge Cornelissen
Approvals
Mounting & Optics
Wall - up/down
Direct DD4
Indirect UD2
Indirect UD3
Declare
PoE
