Le Louvre™ Continuous Recessed

The striking new concept in louver technology is disrupting the linear lighting category, and taking glare control to new heights. Our award-winning design with diagonal cross-hatched construction of the louver in a soft concave shape provides not just visual comfort but a touch of panache unseen in traditional linear lighting. Louvers are available in white for higher performance, black for the highest glare control, and rich satinized finishes - chrome, gold, champagne, for elegant interior designs.

DOWNLOAD SPEC SHEET

Imperial
Imperial Metric

Downloads

Tech Specs

Body

Aluminum.

Finish

Powder coated.

Drivers

HPF electronic drivers for 120-277V, 347V (EU-240V). The driver is integral to the fixture housing.

Diffuser

Opal acrylic. 2.4" width.

Integral Emergency system

Emergency option provides a 1.5 hour (3 hours for EU) emergency lighting facility. The self contained system includes the inverter module, NiCad batteries, LED charge indicator and test switch (NA only). Not available with a 347V supply.

Grid Ceilings

Dimensions are nominal for grid ceiling fixtures. Fixtures are designed to fit within standard grid ceiling systems.

PoE

Can be integrated into your data network via Power over Ethernet (PoE) connectivity.

BIOS

For circadian lighting, consult factory.

Reported L70 @25°C (77°F)

> 60,000 hrs @ 1200 lumens/ft (3600 lumens/m).

Estimated L70 @25°C (77°F)

> 149,000 hrs @ 1200 lumens/ft (3600 lumens/m).

Delivered lumens

Delivered lumens & LPW based on 4000K CRI 80+

Tunable White

Tunable white available, consult factory.

RGBW

RGBW available, consult factory.

Approvals

Damp Rated.

Designed by

Serge Cornelissen.

Design

US Pat. No. D959,043..

Approvals

  • ETL
  • CE
  • Grounding
  • Damp Location (Indoor Use)
  • Mounting Suited On Flammable Surfaces
  • IP 20

Mounting & Optics

Icon for Recessed Recessed
Icon for Direct DD1 Direct DD1
Icon for Direct DD4 Direct DD4
Icon for Bios Bios
Icon for Declare Declare
Icon for PoE PoE

Product Configurator

LELR1R

Luminaire

Length of Run

Max Length Per Section

Louver

Lm/ft

CRI

CCT

Diffuser

Voltage

Dimming

Ceiling Type & Trim

Emergency

Chicago Plenum

Product Family

Beta-Calco envisions a world where beauty is a baseline standard for the built environment. We drive towards more dynamic and impressive solutions with robust product development.
Le Louvre™ Continuous
Le Louvre™ Continuous Recessed
Le Louvre™ Ceiling
Le Louvre Quad™ Suspended
Le Louvre Systems™ Suspended
Le Louvre™ Continuous Wall
