Ooooh™

OOOOH dazzles up traditional linear lighting concepts with an innovative louver system. An array of ellipses is incurved to conform to a tunnel-shaped profile creating a subtle aesthetic and sublime lighting effect. The louver system not only tempers the starkness of the commonly exposed diffuser and adds an enchanting decorative feature, but also offers visual comfort by minimizing glare. Behind the louver system is either the Comfort diffuser which provides a softer and even distribution of light, or an asymmetric which skews the light for brightening up walls or adding to the ambient light. Ooooh presents a simple way to transform a functional light into a luxurious design feature.

Features

Body

Aluminum.

Finish

Powder coated.

Diffuser

Opal acrylic.

Drivers

HPF electronic drivers for 120-277V, 347V (EU-240V).

Integral Emergency system

Emergency option provides a 1.5 hour (3 hours for EU) emergency lighting facility. The self contained system includes the inverter module, NiCad batteries, LED charge indicator and test switch (NA only). Not available with a 347V supply.

Grid Ceilings

Dimensions are nominal for grid ceiling fixtures. Fixtures are designed to fit within standard grid ceiling systems.

PoE

Can be integrated into your data network via Power over Ethernet (PoE) connectivity.

BIOS

For circadian lighting, consult factory.

Reported L70 @25°C (77°F)

> 60,000 hrs @ 1200 lumens/ft (3600 lumens/m).

Estimated L70 @25°C (77°F)

> 149,000 hrs @ 1200 lumens/ft (3600 lumens/m).

Delivered lumens

Delivered lumens & LPW based on 4000K CRI 80+

Approvals

Damp Location (Indoor use only).

Design

US Pat. No. D969,395.

Mounting and Optics

Icon for Recessed Recessed
Icon for Direct DD1 Direct DD1
Icon for Direct DD4 Direct DD4
Icon for PoE PoE
Icon for Bios Bios

Downloads

Approvals

  • ETL
  • CE
  • Grounding
  • Damp Location (Indoor Use)
  • Mounting Suited On Flammable Surfaces
  • IP 20
