Rodeo™
Continuous

Rodeo’s flexible spotlight design combined with a high-performance linear system creates a multifunctional luminaire that serves a variety of lighting needs. The modular system employs direct light, indirect light, and spotlights to deliver 3 layers of lighting.   The innovative Rodeo Flip design expands the sphere of adjustability which allows Rodeo to adapt to various space layouts. Combined with regressed optics, the luster from anodized bezels and trims bring visual and aesthetic comfort.

DOWNLOAD SPEC SHEET

Tech Specs

Body

Aluminum.

Finish

Powder coated.

Suspension

Steel cables.

Power cable

Silver braided.

Drivers

HPF electronic drivers for 120-277V, 347 (EU-240V). The driver is integral to the fixture housing.

Diffuser

Opal acrylic.

PoE

Can be integrated into your data network via Power over Ethernet (PoE) connectivity.

Mechanical

Luminaires mount directly over J box (by others).

Remote Emergency system

Emergency option provides a 1.5 hour (3hours for EU) emergency lighting facility. The remote system includes the inverter module, NiCad batteries and a remote wall/ceiling LED charge indicator and test switch. Maximum distance between wall/ceiling plate and luminaire is 15' (4.5m). Test switch fits a single gang box (not supplied).

Sensors

Compatible with Avi-On, Casambi, Enlighted, Lutron Vive, nLight, NX Lighting Controls, Osram, Philips, and others. Consult factory.

Reported L70 @25°C (77°F)

> 55,000 hrs @ 2000 lumens/ft (6000 lumens/m)

Estimated L70 @25°C (77°F)

> 165,000 hrs @ 2000 lumens/ft (6000 lumens/m)

Delivered lumens

Delivered lumens & LPW based on 4000K CRI 90+

Approvals

Damp Rated.

Designed by

Serge Cornelissen

Design

US Design Patent Pending.

Approvals

  • ETL
  • CE
  • Grounding
  • Damp Location (Indoor Use)
  • Mounting Suited On Flammable Surfaces
  • IP 20

Mounting & Optics

Icon for Suspended Direct Suspended Direct
Icon for Suspended Direct/Indirect Suspended Direct/Indirect
Icon for Direct DD4 Direct DD4
Icon for Indirect UD1 Indirect UD1
Icon for Indirect UD3 Indirect UD3
Icon for BA 25° BA 25°
Icon for BA 42° BA 42°
Icon for Declare Declare
Icon for PoE PoE

Product Configurator

CR90 / DD4

Spotlights At Start of Section

Spotlights At End of Section

Direct Diffuser

Sensors
