Timpani RD™ Ceiling

So much can be done with TIMPANI RD. The disk is a perennial classic in architectural design due to its versatile look. It is minimalist, elegant, bold, graceful, or fun; it can blend in or make a statement. Any feeling or style can be attributed to TIMPANI RD, especially with a variety of finish options, sizes, and lumen packages to attain the ideal level of illumination.

DOWNLOAD SPEC SHEET

Tech Specs

Body and trim

Steel and aluminum.

Finish

Powder coated.

Diffusers

Opal polycarbonate.

Sensors

Consult factory regarding sensor compatibility.

Integral Emergency system

Emergency option provides a 1.5 hour (3 hours for EU) emergency lighting facility. The self contained system includes the inverter module, NiCad batteries, LED charge indicator and test switch (NA only). Not available with a 347V supply.

Drivers

Integral, HPF electronic drivers for 120-277V, 347V (EU-240V). The driver is integral in the fixture housing.

PoE

Timpani RD can integrate into your data network via Power over Ethernet (PoE) connectivity.

Delivered Lumens

Delivered lumens & LPW based on 4000K (min 80 CRI).

Reported L70 @25°C (77°F)

> 50,000 hrs.

Approvals

Damp Rated.

Approvals

  • ETL
  • CE
  • Grounding
  • Mounting Suited On Flammable Surfaces
  • IP 20

Mounting & Optics

Icon for Ceiling Direct Ceiling Direct
Icon for Declare Declare
Icon for PoE PoE

Product Configurator

Product Family
