Velop™ Suspended Configurator

Name: Velop™ Suspended
Brand: Beta-Calco

Velop™ Suspended

VELOP takes shape with a sculpted arc, rounded end caps, and a lens that flows seamlessly from bottom to top, delivering a continuous flow of light that softens architectural lines. Designed to balance structure and fluidity, VELOP integrates seamlessly into a variety of spaces—whether as a sculptural focal point or a refined complement to architectural elements. The wrapped diffuser fully envelops the frame, ensuring consistent illumination without visible seams or interruptions. This seamless design enhances both aesthetics and performance, providing uniform light distribution across the entire fixture. The curved ends further reinforce this effect, allowing the lens to transition smoothly around the edges, avoiding harsh cutoffs and maintaining a cohesive, fluid appearance. Available in arc-shape and straight configurations, VELOP adapts to dynamic environments, offering scalable solutions for open offices, collaborative workspaces, hospitality settings, and beyond. Its versatility makes it a refined yet impactful lighting solution—one that enhances not just the space but the experience within it.

Downloads

Tech Specs

Body

Aluminum.

Finish

Powder coated.

Suspension

P.O.S. Power over suspension cable.

Diffuser

Protruding Lens 0.08" (2.1mm)

Remote Emergency

Emergency option provides a 1.5 hour (3 hours for EU) emergency lighting facility. The remote system includes the inverter module, NiCad batteries and a remote wall/ceiling LED charge indicator and test switch (NA only) Maximum distance between wall/ceiling plate and luminaire is 15' (4.5m). Test switch fits a single gang box (not supplied).

Drivers

Remote, HPF electronic drivers for 120-277V (EU-240V) dimming. Wire size 18 AWG - max distance (from fixture to drivers) 40' (12.2m), wire size 16 AWG - max distance 60' (18.3m), wire size 14 AWG - max distance 90' (27.4m). Drivers must be accessible after installation. Drivers are either remote mounted or integral to the canopy.
