Box™

General Specification

Body and trim: Steel and aluminum.

Finish: Powder coated.

Power cable: Silver braided.

Drivers: Integral, HPF electronic drivers 120/277V (EU-240V), 0-10V, 10% dimming.

Mechanical: Luminaires mount directly over J box (by others - North America only).

Delivered Lumens: Delivered lumens & LPW based on 3000K (min 80 CRI).

Approvals: Damp Location (Indoor use only).

Box™

Box - PRO01 - 1

Box - PRO02 - 2

Box - PRO03 - 3

Mounting and Optics

Icon for Suspended Direct

Suspended Direct

Downloads

Approvals

Share this fixture

Configurator

You selected

qty

Luminaire

75 1011 1, 3218 lms 75 1012 2, 6436 lms 75 1014 4, 12872 lms

CCT

30 3000K (min 80 CRI) 35 3500K (min 80 CRI) 40 4000K (min 80 CRI)

Reflector

NB Narrow Beam (14°) MB Medium Beam (22°) WB Wide Beam (38°)

Finish

BL Black MS Silver Metallic WH White

Dimming

D1 0-10V dimming (1%) D2 0-10V Dimming (0.1%) DA DALI dimming (0.1%) DL DALI dimming (1%) L1 Lutron L3DA3W Hi-Lume 1%, 3 Wire
