Cylinder™

The CYLINDER series offers flexible lighting solutions for interior spaces, available in both ceiling and stem mount options. Its sleek, hardware-free design seamlessly integrates into any environment, emphasizing performance over aesthetics. Featuring a tiltable gimbal with +/- 30° pivot, 10° incremental locks, and 180° rotation, the CYLINDER provides precise directional control for strategic light distribution. Advanced optics, including Multi-Lens Array (MLA) and Chip on Board (COB), ensure tailored illumination for various commercial settings. With up to 125 LPW, the CYLINDER delivers best-in-class lumen efficacy. Innovative thermal management enhances durability, minimizes energy waste, and reduces operational costs. Ideal for optimizing lighting in conference rooms, galleries, or retail layouts, the CYLINDER ensures comfort and visibility. Illuminate interiors with focused beams to accentuate artwork or create task-oriented environments. The CYLINDER series redefines interior lighting, combining performance and precision to create dynamic, professional spaces.

DOWNLOAD SPEC SHEET

Imperial
Imperial Metric

Downloads

Tech Specs

Housing

Die-cast and extruded aluminum.

External Screws

Stainless steel.

Mounting

The Ceiling and Pendant mount to a 4"x4" octagonal junction box (supplied by others). The pendant allows for a sway of up to 42 degrees in any direction.

Finish

Powder coated.

Drivers

HPF, electronic for 120-277V (EU-240V).

Delivered Lumens

Delivered lumens & LPW based on 4000K (min 80 CRI).

Hardware

Vandal proof hardware included.

REPORTED L70 @25°C (77°F)

> 60,000 hrs

Approvals

  • ETL
  • CE
  • Grounding
  • Damp Location (Indoor Use)
  • Mounting Suited On Flammable Surfaces

Mounting & Optics

Icon for Ceiling Ceiling
Icon for Suspended Direct Suspended Direct
Icon for 15° 15°
Icon for 30° 30°
Icon for 50° 50°
Icon for 70° 70°
Icon for Declare Declare

Product Configurator

DR06 / CR80

Luminaire

Diameter

Direction

Light Source

CRI

CCT

Distribution

Lumens

Voltage

Dimming

Suspension (Stem Mount)

Fixture Finish

Bezel Finish

Canopy & Stem Finish

Product Family
