Matrex RD Dual Surface™
Product Overview

MATREX is a family of spotlights packed with power for projecting light at great distances. With best-in-class thermal management and hidden heat sinks, MATREX’s form factor is significantly smaller than traditional spotlights. Multiple mounting systems are available, providing a variety of functions that work in a range of applications, especially those with multiple ceiling heights.

Features

Body and trim

Steel and aluminum.

Finish

Powder coated as specified. Custom paint finishes available to special order.

Drivers

HPF, electronic, 120-277V, 347V (EU-240V).

Mechanical

Luminaires mount to a junction box (by others - North America only).

Remote emergency system (North America only)

Emergency option provides a 1.5 hour emergency lighting facility. The remote system includes the inverter module, NiCad batteries and a remote wall/ceiling LED charge indicator and test switch (maximum distance between wall/ceiling plate and luminaire is 4.5m/15’). Test switch fits a single gang box (not supplied).

Reported L70 @25°C (77°F)

> 60,000 hrs.

Estimated L70 @25°C (77°F)
> 171,000 hrs.

Delivered lumens

Delivered lumens & lpw based on 4000K, CRI 80+.

Designed by

Serge Cornelissen.

Mounting and Optics

Icon for Ceiling Direct Ceiling Direct
Icon for Wall - up/down Wall - up/down
Icon for Wall - up Wall - up
Icon for Wall - down Wall - down
Icon for 15° 15°
Icon for 30° 30°
Icon for 50° 50°
Icon for 70° 70°

Downloads

Approvals

  • ETL
  • CE
  • Grounding
  • Damp Location (Indoor Use)
  • Mounting Suited On Flammable Surfaces
  • IP 20
