Micro Triangle SE™

WEB PIN™192

General Specification

Product Overview:

  • Sleek 1” (25mm) profile
  • Robust aluminium construction
  • High efficiency frosted acrylic diffuser with 115 LPW delivered
  • Available in five sizes, three different colour temperatures and multiple finishes including our signature Light Cherry & Dark Walnut wood grain.
  • Larger sizes and multi-tier pendants available for custom order.

Body: Aluminum, Equilateral Triangle

Finish: Powder coated for standard finishes (black, Silver Metallic & white).

Suspension: Stainless steel cables.

Power cable: Silver braided.

Drivers: HPF electronic drivers for 120-277V (EU-240V), 0-10V, 1% dimming.

Remote Mounting Of Drivers: Wire size 18 AWG - max distance (from fixture to drivers) 40', wire size 16 AWG - max distance 60', wire size 14 AWG - max distance 90'. Drivers must be accessible after installation.

Mechanical: Luminaires attached directly to the J box (by others - North America only).

Diffusers: Frosted acrylic.

L70 @25oC: > 60,000 hrs.

Delivered Lumens: Delivered lumens & LPW based on 4000K (min 80 CRI) for White LEDs only.

Approvals: Damp Location (Indoor use only).



See Approvals
Suspended Inside Suspended Inside General Diffuse General Diffuse

Specify Luminaire

Code Length Power (LED) Light Direction Delivered lms LPW
24" 20W Inside 2321 116
36" 30W Inside 3633 122
48" 40W Inside 4799 120

Specify CCT/Color

Specify Suspension

Specify Finish

Note:  The canopy will be white for fixtures with the wood grain finishes Z1 & Z2.

Specify Lumen & Wattage Reduction

PR0 not available for 984210.  Note: Custom reduction percentages available upon request.

Specify Dimming Option (Remote Only)

0-10V, 1% dimming standard
