Sentis™

WEB PIN™580

General Specification

Housing: Die-Formed steel.

Horizontal bars: Die-cast zinc.

Perforated accents: Steel, finished as specified.

Finish: Powder coated paint or plated.

Front diffuser: UV stabilized polycarbonate with vertical ribs.

Rear side (halo) diffuser: Extruded opal acrylic.

Upper and lower dust covers: Opal polycarbonate.

Drivers: HPF electronic, 120-277V (EU-240V). 0-10V, 1% dimming standard.

Mechanical: Mounts directly to a standard electrical junction box (by others - North America only). Additional mounting points provided. Mounting hardware (by others).

Delivered Lumens: Delivered lumens & LPW based on 3000K (min 80 CRI).

See Approvals
Wall Front/Back Wall Front/Back General Diffuse General Diffuse

Specify Luminaire

Code Power (LED) Delivered lms LPW Type (A) Type (B)
14W 1311 93 14"
20W 1865 95 18"
28W 2592 94 24"
47W 4333 92 36"
59W 5523 94 48"

Specify CCT

Specify Fascia

Specify Finish

F39 & F40 have a one time set-up charge regardless of quantity.

Specify Options
