Xacara NC™

General Specification

Housing: Steel. For new construction. Non I.C. rated housing (NA only). Not suitable for insulated ceilings.

Array housings: Die cast aluminium.

Gimbal: Fully articulating on two axes.

Trim: Removable flange 19mm/0.75" wide.

Trimless: Housing includes mesh plates for trimless installation in drywall or plaster ceilings. Drywall/plaster compound to be applied up to edge of fixture to achieve a clean edge. Both trim and trimless designs suitable for ceiling thickness 12mm/0.5" to 31mm/1.25".

Mounting: Butterfly brackets, C channel, T bar fasteners, bar hangers and suspension points.

Electrical: Access above ceiling not required. Through branch wiring. Driver access from below for ease of maintenance.

Reflectors: Highly reflective, specular finish, vacuum plated.

Protective lens: Clear glass. 26W LED fixtures only.

Finish: Powder coated, as specified.

Drivers: HPF electronic for 120-277V (EU240V). 0-10V dimming (10%).

Integral Emergency system (NA only): Emergency option provides a 1.5 hour emergency lighting facility. The self contained system includes the inverter module, NiCad batteries, LED charge indicator and test switch.

L70 @25oC (77oF): >60,000 hrs.

Delivered Lumens: Delivered lumens & LPW based on 3000K (min 80 CRI).

Approvals: Damp Location (Indoor use only).

Note: Photometric testing performed using LM79 procedures.
See Approvals
Recessed 26W-36° 26W-70° 38W-28° 38W-47°

Specify Luminaire

Code Type
1 spotlight head
2 spotlight heads
3 spotlight heads
4 spotlight heads - Linear
4 spotlight heads - Quad
5 spotlight heads
6 spotlight heads


Code Power (LED) CCT CRI Size Delivered lms LPW
26W 3000K 80 A 2085 80
26W 3000K 90 A 1689 65
26W 3500K 80 A 2127 81
26W 3500K 90 A 1770 68
26W 4000K 80 A 2169 83
26W 4000K 90 A 1820 70
38W 3000K 80 B 3045 80
38W 3000K 90 B 2471 65
38W 3500K 80 B 3133 82
38W 3500K 90 B 2674 70
38W 4000K 80 B 3185 83
38W 4000K 90 B 2686 70

Specify Reflectors

Medium 36° (Bridgelux-26W)
Extra Wide 70° (Bridgelux-26W)
Medium 28° (Bridgelux-38W)
Wide 47° (Bridgelux-38W)

Specify Head/Gimbal finish

Head/Gimbal finish
Silver Metallic

Specify Internal Finish

Internal Finish

Specify Trim Finish

Trim Finish
Silver Metallic
No Trim (Trimless)

Specify Dimming

0-10V Dimming 1%
0-10V Dimming 0.1%
DALI Dimming 1%
DALI Dimming 0.1%
Lutron L3DA3W Hi-Lume 1%
Lutron L3DAE Hi-Lume 1% EcoSystem

Specify Options

Options shown are available in North America only.
