Block™
Ceiling

BLOCK, while designed in the classic form, is a linear system like no other.   It is unique in two magnitudes. Firstly on output, BLOCK surpasses the typical levels of output and efficacy. Secondly, BLOCK delivers on specification capabilities. Nearly every component has alternatives allowing designers to configure a luminaire designed precisely to the needs of the space ~ a bona fide architectural system. BLOCK is the new go-to linear that adapts to a variety of performance needs and budgetary requirements. BLOCK is available in five stand-alone lengths ranging from 4ft to 12ft.

Features

Body

Aluminum.

Finish

Powder coated.

Diffuser

Opal acrylic.

Drivers

HPF electronic drivers for 120-277V, 347 (EU-240V).

BIOS

For circadian lighting, consult factory.

PoE

Can be integrated into your data network via Power over Ethernet (PoE) connectivity.

Reported L70 @25°C (77°F)

> 60,000 hrs @ 1400 lumens/ft (4600 lumens/m)

Estimated L70 @25°C (77°F)

> 165,000 hrs @ 1400 lumens/ft (4600 lumens/m)

Delivered lumens

Delivered lumens & LPW based on 4000K CRI 80+

Mechanical

Luminaires mount directly over J box (by others).

Approvals

Damp Location (Indoor use only).

Design

US Design Patent Pending.

Integral Emergency system

Emergency option provides a 1.5 hour (3 hours for EU) emergency lighting facility. The self contained system includes the inverter module, NiCad batteries, LED charge indicator and test switch (NA only). Not available with a 347V supply.

Mounting and Optics

Icon for Ceiling Direct Ceiling Direct
Icon for Direct DD1 Direct DD1
Icon for Direct DD2 Direct DD2
Icon for Direct DD3 Direct DD3
Icon for Bios Bios
Icon for Declare Declare
Icon for PoE PoE

Downloads

Approvals

  • ETL
  • CE
  • Grounding
  • Damp Location (Indoor Use)
  • Mounting Suited On Flammable Surfaces
  • IP 20
