BLOCK, while designed in the classic form, is a linear system like no other. It is unique in two magnitudes. Firstly on output, BLOCK surpasses the typical levels of output and efficacy. Secondly, BLOCK delivers on specification capabilities. Nearly every component has alternatives allowing designers to configure a luminaire designed precisely to the needs of the space - a bona fide architectural system. BLOCK is the go-to linear that adapts to a variety of performance needs and budgetary requirements. Use our new preconfigured quads to create and complement grid effects.


Features

Body

Aluminum.

Finish

Powder coated.

Suspension

Steel cables.

Power cable

Silver braided.

PoE

Can be integrated into your data network via Power over Ethernet (PoE) connectivity.

BIOS
For circadian lighting, consult factory.

Integral Emergency system

Emergency option provides a 1.5 hour (3 hours for EU) emergency lighting facility. The self contained system includes the inverter module, NiCad batteries, LED charge indicator and test switch (NA only). Not available with a 347V supply.

Sensors

Compatible with Avi-On, Casambi, Enlighted, Lutron Vive, nLight, NX Lighting Controls, Osram, Philips, and others. Consult factory.

Drivers

HPF electronic drivers for 120-277V, 347 (EU-240V). The driver is integral to the fixture housing.

Mechanical

Luminaires mount directly over J box (by others).

Diffuser

Opal acrylic.



Reported L70 @25°C (77°F)

> 60,000 hrs @ 2000 lumens/ft (6000 lumens/m)

Estimated L70 @25°C (77°F)

> 165,000 hrs @ 2000 lumens/ft (6000 lumens/m)

Tunable White

Tunable white available, consult factory.

Delivered lumens

Delivered lumens & LPW based on 4000K CRI 80+

Approvals

Damp Rated.

Design

US Design Patent Pending.

Mounting and Optics

Icon for Suspended Direct Suspended Direct
Icon for Suspended Direct/Indirect Suspended Direct/Indirect
Icon for Direct DD2 Direct DD2
Icon for Direct DD3 Direct DD3
Icon for Indirect Indirect
Icon for Bios Bios
Icon for Declare Declare
Icon for PoE PoE

Downloads

Approvals

  • ETL
  • CE
  • Grounding
  • Damp Location (Indoor Use)
  • Mounting Suited On Flammable Surfaces
  • IP 20

Share this fixture

Configurator

You selected

Luminaire

BLQP1P01 32" Sq, Direct BLQP1P02 56" Sq, Direct BLQP1P05 32" x 56", Direct BLQP2P01 32" Sq, Direct/Indirect BLQP2P02 56" Sq, Direct/Indirect BLQP2P05 32" x 56", Direct/Indirect

Lumens/ft (Direct)

LPF020 200 lm/ft LPF040 400 lm/ft LPF060 600 lm/ft LPF080 800 lm/ft LPF100 1000 lm/ft LPF120 1200 lm/ft LPF140 1400 lm/ft

Lumens/ft (Indirect)

LPG000 Not required LPG020 200 lm/ft LPG040 400 lm/ft LPG060 600 lm/ft LPG080 800 lm/ft LPG100 1000 lm/ft LPG120 1200 lm/ft LPG140 1400 lm/ft ¹ LPG165 1650 lm/ft ¹

CRI

CR80 CRI 80+ CR90 CRI 90+

CCT Direct

CTA30 3000K CTA35 3500K CTA40 4000K

CCT Indirect

CTB00 Not required CTB30 3000K CTB35 3500K CTB40 4000K

Direct Diffuser

DD2 Batwing diffuser DD3 Diffused Light Diffuser

Indirect Diffuser

UD0 Not required UD1 Clear diffuser (Batwing distribution)

Uplight Blackout Plate

UB00 Not required UB Blackout plate ¹

Voltage

V1 120/277V V2 240V ¹ V3 347V ² V4 Low Voltage ³

Dimming

DA01 0-10V Dimming 1.0% DA02 0-10V Dimming 0.1% ¹ DA20 DALI Dimming 0.1% ¹ DA21 DALI Dimming 1.0% ¹ DA30 DSI/switchDim ² DA45 PoE ³

Ceiling Type

G1 Grid ceiling ¹ H1 Hard ceiling ²

Suspension

HLA03 3ft cable suspension HLA06 6ft cable suspension HLA09 9ft cable suspension

Fixture Finish

White FA01 White Black Metallic Textured FA02 Black Metallic - Textured Silver Metallic Textured FA20 Silver Metallic - Textured Gold Metallic FA25 Gold Metallic Wood Grain - Light Cherry FA27 Wood grain - Light Cherry ¹ Wood Grain - Dark Walnut FA28 Wood grain - Dark Walnut ¹ Midnight Blue Metallic Textured FA44 Midnight Blue Metallic - Textured Copper Metallic FA45 Copper Metallic Charcoal Metallic Textured FA46 Charcoal Metallic - Textured Bronze Metallic Textured FA47 Bronze Metallic - Textured Charcoal Metallic Textured FA52 Champagne Metallic Red Metallic Textured FA53 Red Metallic - Textured

Emergency

E0 Not required E1 Emergency system - Integral E3 Emergency generated circuit - Remote ¹

Circuits

CS1 Single circuit ¹ CS2 Dual circuit (Direct vs. Indirect) ²
