Ring 3™ Suspended

RING 3 is our 2nd generation circular performance pendant. Now with a slender 3” profile, the lightweight design works well as a low-hanging ambient light and is ideal for lower ceilings. The new design still delivers matchless light outputs and multiple control integrations including PoE and wellness technology including BIOS and Dim to Warm. Indirect light is available with our powerful Batwing optic which provides wider light coverage and is an effective way to add to the ambient illumination. For sound comfort, RING 3 is available with an acoustic panel up to 8’, designed to absorb echo and reverberation associated with open-concept spaces, exposed concrete, open ceilings, and large windows.

DOWNLOAD SPEC SHEET

Imperial
Imperial Metric

Downloads

Tech Specs

Body and trim

Steel and aluminum.

Finish

Powder coated.

Power cable

Silver braided.

Diffusers

Opal polycarbonate direct, batwing indirect, supplied in sections.



Remote Emergency

Emergency option provides a 1.5 hour (3 hours for EU) emergency lighting facility. The remote system includes the inverter module, NiCad batteries and a remote wall/ceiling LED charge indicator and test switch (NA only) Maximum distance between wall/ceiling plate and luminaire is 15' (4.5m). Test switch fits a single gang box (not supplied).

Drivers

Integral, HPF electronic drivers for 120-277V (EU-240V). The driver is integral to the fixture housing.

Suspension

Steel cables. Recommended minimum mounting heights: 1ft (305mm). Maximum angle tilt 5°.

PoE

Ring 3 can integrate into your data network via Power over Ethernet (PoE) connectivity.

Mechanical

Luminaires mount directly over J box (by others - North America only).

Delivered Lumens

Delivered lumens & LPW based on 4000K (min 90 CRI) for White LEDs only. Data shown at MAX values.

Sensors

Consult factory regarding sensor compatibility.

L70 @25°C (77°F)

> 50,000 hrs.

Approvals

Damp Rated.

Approvals

  • ETL
  • CE
  • Grounding
  • Damp Location (Indoor Use)
  • Mounting Suited On Flammable Surfaces
  • IP 20

Mounting & Optics

Icon for Suspended Direct Suspended Direct
Icon for Suspended Direct/Indirect Suspended Direct/Indirect
Icon for Acoustic Acoustic
Icon for Declare Declare
Icon for Dim to Warm Dim to Warm
Icon for PoE PoE

Product Configurator

Luminaire

RGTP1P02 2ft, Direct, 4600 lms Direct RGTP1P03 3ft, Direct, 6700 lms Direct RGTP1P04 4ft, Direct, 8800 lms Direct RGTP1P05 5ft, Direct, 11000 lms Direct RGTP1P06 6ft, Direct, 13000 lms Direct RGTP1P07 7ft, Direct, 15000 lms Direct RGTP1P08 8ft, Direct, 21000 lms Direct RGTP1P09 9ft, Direct, 24000 lms Direct RGTP1P12 12ft, Direct, 32000 lms Direct RGTP1P18 18ft, Direct, 48000 lms Direct RGTP2P02 2ft, Direct/Indirect, 4600 lms Direct, 2200 lms Indirect RGTP2P03 3ft, Direct/Indirect, 6700 lms Direct, 4400 lms Indirect RGTP2P04 4ft, Direct/Indirect, 8800 lms Direct, 4400 lms Indirect RGTP2P05 5ft, Direct/Indirect, 11000 lms Direct, 7300 lms Indirect RGTP2P06 6ft, Direct/Indirect, 13000 lms Direct, 8800 lms Indirect RGTP2P07 7ft, Direct/Indirect, 15000 lms Direct, 12000 lms Indirect RGTP2P08 8ft, Direct/Indirect, 21000 lms Direct, 8800 lms Indirect RGTP2P09 9ft, Direct/Indirect, 24000 lms Direct, 13000 lms Indirect RGTP2P12 12ft, Direct/Indirect, 32000 lms Direct, 18000 lms Indirect RGTP2P18 18ft, Direct/Indirect, 48000 lms Direct, 31000 lms Indirect

Lumens (Direct)

Lumens (Indirect)

CRI

CCT (Direct)

CCT (Indirect)

Uplight Diffuser

Voltage

Dimming (Direct)

Dimming (Indirect)

Suspension

Fixture Finish

Canopy Finish

Acoustic Panel Color

Emergency

Circuit

Controls

Product Family
