Micro Ring Direct™ Suspended

MICRO RING DIRECT sets a new performance benchmark in decorative rings, boasting a best-in-class lumen efficacy of 104 LPW. This performance is not just about brightness but about the quality of light. Its high-efficiency, flexible diffuser snugly fits the frame, eliminating any light leakage while ensuring a uniform and seamless diffusion of light. The slim design of MICRO RING DIRECT, available in 6 diameters ranging from 2 feet to 7 feet, makes it ideal for crafting grand, multi-tiered circular installations. This versatile ring is part of the larger MICRO RING family, which includes five additional light emission options for layered lighting effects. Whether used as a solitary statement piece or in a composition, MICRO RING DIRECT’s impact is undeniable. Moreover, MICRO RING DIRECT addresses acoustic needs with an optional acoustic panel for sizes up to 4 feet in diameter. These panels are specifically designed to reduce echo and reverberation commonly found in modern open-plan spaces, areas with exposed concrete, open ceilings, and rooms with large windows. For a touch of whimsy and creative flair, MICRO RING can be combined with other shapes like MICRO TRIANGLE or MICRO QUAD, adding a dynamic and playful dimension to any space.

DOWNLOAD SPEC SHEET

Imperial
Imperial Metric

Downloads

Tech Specs

Body and trim

Aluminum.

Finish

Powder coated.

Suspension

Steel cables.

Power cable

Silver braided.

Remote Emergency

Emergency option provides a 1.5 hour (3 hours for EU) emergency lighting facility. The remote system includes the inverter module, NiCad batteries and a remote wall/ceiling LED charge indicator and test switch (NA only) Maximum distance between wall/ceiling plate and luminaire is 15' (4.5m). Test switch fits a single gang box (not supplied).

Drivers

Remote, HPF electronic drivers for 120-277V (EU-240V) dimming. Wire size 18 AWG - max distance (from fixture to drivers) 40' (12.2m), wire size 16 AWG - max distance 60' (18.3m), wire size 14 AWG - max distance 90' (27.4m). Drivers must be accessible after installation. Drivers are either remote mounted or integral to the canopy depending on the size of the fixture.

Mechanical

Luminaires mount directly over J box (by others - North America only).

PoE

Integrates into your data network via Power over Ethernet (PoE) connectivity.

Acoustic Panels Class A Fire Rating

ASTM E-84 material.

Acoustic Panels NRC Rating

0.80

Acoustic Panels Material

100% recycled polyester fiber (PET).

Acoustic Panels Thickness

12mm (0.5")

Sensors

Consult factory regarding sensor compatibility.

Diffuser

Protruding Lens 0.08" (2.1mm).

Delivered Lumens

Delivered lumens & LPW based on 4000K (min 80 CRI).

L70 @25°C

> 60,000 hrs.

Approvals

Damp Rated.

Approvals

  • ETL
  • CE
  • Grounding
  • Damp Location (Indoor Use)
  • Mounting Suited On Flammable Surfaces
  • IP 20

Mounting & Optics

Icon for Suspended Direct Suspended Direct
Icon for Acoustic Acoustic
Icon for Declare Declare
Icon for PoE PoE

Product Configurator

Luminaire

Efficiency

Lm/ft

CRI

CCT

Voltage

Dimming (Remote)

Suspension

Fixture Finish

Canopy Finish

Acoustic Panel Color

Emergency

Product Family
