Matrex Single™

General Specification

Product Overview:

  • Sleek compact size offering superior performance.
  • Unique cooling mechanism with no visible heat sink.
  • 4 beam angles with precise performance - 15⁰, 30⁰, 50⁰ and 70⁰.
  • 32.5⁰ fixture angle adjustability.
  • Suspension points originate from the side allowing for unobstructed uplight.
  • Cutting edge optics concentrate the light in your desired beam angle, without color-over-angle discoloration.
  • Multiple stunning finishes to enhance any space.

Body and trim: Steel and aluminum.

Finish: Powder coated as specified. Custom paint finishes available to special order.

Suspension: Steel cables.

Power cable: Silver braided.

Drivers: HPF, electronic, 120-277V, 347V (EU-240V).

Integral emergency system: Emergency option provides a 1.5 hour (3 hours for EU) emergency lighting facility. The self contained system includes the inverter module, NiCad batteries, LED charge indicator and test switch (NA only). Integral emergency EU luminaires have a 17" (434mm) x 8.3" (210mm) x 2.3" (58mm) canopy with LED charge indicator. Not available with a 347V supply.  Drivers are in the canopy.

Mechanical: Luminaires mount to a junction box or switch box (by others - North America only), depending on canopy selection.

Reported L70 @25°C (77°F): > 60,000 hrs.

Estimated L70 @25°C (77°F): > 171,000 hrs.

Delivered lumens: Delivered lumens & lpw based on 4000K, CRI 80+.

Designed by:  Serge Cornelissen.





See Approvals
Suspended Direct Suspended Indirect 15° 30° 50° 70°

Specify Luminaire

Luminaire
Code Light Direction Wattage Delivered lms LPW
Direct 82W 9200 130
Indirect 82W 9200 130

Specify Lumens

Lumens
2300
4600
6900
9200

Specify CRI

CRI
CRI 80+
CRI 90+

Specify CCT

CCT
3000K
3500K
4000K

Specify Beam Angle

Angle
15°
30°
50°
70°

Specify Voltage

Voltage
120/277V
240V ¹
347V ²

Specify Dimming

Dimming
0-10V Dimming 1.0%
0-10V Dimming 0.1% ¹
DALI Dimming 0.1% ¹
DALI Dimming 1.0% ¹
DSI/switchDim ¹ ²
DMX Dimming ¹ ³

Specify Fixture Finish

Finish - Fixture
White
Black Metallic - Textured
Silver Metallic - Textured
Gold Metallic
Midnight Blue Metallic - Textured
Charcoal Metallic - Textured
Bronze Metallic - Textured
Red Metallic - Textured

Specify Canopy

Canopy
Canopy A ¹
Canopy B ²
Canopy C ¹ ²
Canopy Emergency ¹

Specify Canopy Finish

Finish - Canopy
White
Black Metallic - Textured
Silver Metallic - Textured
Gold Metallic
Midnight Blue Metallic - Textured
Charcoal Metallic - Textured
Bronze Metallic - Textured
Red Metallic - Textured

Specify Snoot

Snoot
Standard Snoot - Black
Standard Snoot - White
Long Snoot - Black
Long Snoot - White

Specify Emergency

Emergency
Emergency system not required
Emergency system - Integral ¹ ²
