Micro Ring Indirect™ Suspended

With a super slim profile and 6 diameters ranging from 2’ to 7’, MICRO RING INDIRECT is ideal for creating sizable multi-tiered circular arrangements. The ring emits indirect light only and can be coordinated with 5 other emission options in the MICRO RING family for creating light layers. Buoyant and energetic, MICRO RING INDIRECT is just as impactful as a single standalone piece, especially with the halo effect created from the uplight. For sound comfort, MICRO RING INDIRECT is available with an acoustic panel designed to absorb echo and reverberation associated with open-concept spaces, exposed concrete, open ceilings, and large windows. For a whimsical style, combine MICRO RING with MICRO TRIANGLE or MICRO QUAD.

DOWNLOAD SPEC SHEET

Imperial
Imperial Metric

Downloads

Tech Specs

Body and trim

Aluminum.

Finish

Powder coated.

Suspension

Steel cables.

Power cable

Silver braided.

Remote Emergency

Emergency option provides a 1.5 hour (3 hours for EU) emergency lighting facility. The remote system includes the inverter module, NiCad batteries and a remote wall/ceiling LED charge indicator and test switch (NA only) Maximum distance between wall/ceiling plate and luminaire is 15' (4.5m). Test switch fits a single gang box (not supplied).

Remote Mounting Of Drivers

Wire size 18 AWG - max distance (from fixture to drivers) 40' (12.2m), wire size 16 AWG - max distance 60' (18.3m), wire size 14 AWG - max distance 90' (27.4m). Drivers must be accessible after installation. .

Drivers

HPF electronic drivers for 120-277V, 0-10V, 1% dimming. The driver is integral to the fixture canopy or remote mount depending on which options are selected.

PoE

Micro Ring Indirect can itegrate into your data network via Power over Ethernet (PoE) connectivity.

Acoustic Panels NRC Rating

0.80.

Acoustic Panels Class A fire Rating

ASTM E-84 material.

Acoustic Panels Material

100% recycled polyester fiber (PET).

Acoustic Panels Thickness

12mm (0.5").

Mechanical

Luminaires mount directly over J box (by others - North America only).

Delivered Lumens

Delivered lumens & LPW based on 4000K (min 80 CRI).

Diffuser

Protruding Lens 0.08" (2.1mm).

Sensors

Consult factory regarding sensor compatibility.

Reported L70 @25°C (77°F)

> 60,000 hrs.

Approvals

Damp Rated.

Approvals

  • ETL
  • CE
  • Grounding
  • Damp Location (Indoor Use)
  • Mounting Suited On Flammable Surfaces
  • IP 20

Mounting & Optics

Icon for Suspended Indirect Suspended Indirect
Icon for Acoustic Acoustic
Icon for Indirect Indirect
Icon for Declare Declare
Icon for PoE PoE

Product Configurator

Luminaire

Efficiency

Lumens

CRI

CCT

Voltage

Dimming (Remote)

Suspension

Fixture Finish

Canopy Finish

Acoustic Panel Color

Emergency
